Welcome to visit PowMr. Introduction of Sunshine Grid Tie Inverter for Wind Turbine. Sunshine Grid Tie Power Inverter is the world’ s most technologically advanced inverter for use in utility-interactive applications. This manual details the safe installation and opera-tion of the Sunshine Grid Tie Inverter. This integrated system maximizes energy harvest, increases system reliability, and implifies design, installation and management. The small type wind grid tie power inverter can obtain the wind energy from wind turbine, and can tie to the grid through its output cables with no extra equipment. The installation is very convenient and reliable. We call the system combining with small grid tie inverter and wind turbine as’SGWT’. The system includes wind turbine and small grid tie inverter and installation kit, and some “SGWT” also will include controller, dump load resistor. The inverter can be connected to any outlets of utility grid at house. The small grid tie inverter monitors the volume, frequency and phase of the home utility grid, then produce pure sine wave AC power that the frequency and phase are as same as the grid’s, and the volume is a bit higher than the grid’s, then according to the current controlled PWM, to control the output power to the grid. The small grid tie inverter just puts out power when the home grid is on. When the wind turbine is rotating, and the output of the voltage is in the range of the rated input voltage of the inverter, the wind turbine will produces power, and the grid tie inverter will change the power from wind turbine to the home grid. When the total power of electric apparatus that are using in the house is larger than the output power of the inverters, these power from the inverters will be consumed in the house, this will slow down the power meter, otherwise, the difference of the output power of the inverter between the total used power of the apparatus will go out from the house to the out grid. Advantage of the 2G grid tie inverter? The 2nd Generation grid tie inverter, new technical, Higher efficiency. Higher MPPT efficiency, Max 99%. Multiple intelligent protection to ensure safe use. Easy to install and easy to operate. UL1741, IEEE1547, VDE4105 standards. Power Limiter function, Battery discharge function support. Pure sine wave form output, THD. Installing Sunshine Grid Tie Power System involves several key steps: 1. Considering the total capacity of the grid tie power system that you need. Choosing applicable wind turbine for Sunshine Grid Tie Inverter. Selecting accessory for installation of the Grid Tie Power System. Selecting correct model of Sunshine Grid Tie Inverter. Installing wind turbine to suitable place. Installing Sunshine Grid Tie Inverter to suitable place. Connecting Sunshine Grid Tie Power System with cables and connectors. If the input of your Inverter is. 2265V, power is 1000W, please choose: R=3? 45-90V, power is 1000W or 2000W, please choose: R=10? Installing Sunshine Grid Tie Power System to Three Phases Utility Grid. Connecting every system unit to different phase, this can balance all grid tie power to three phases of the utility grid. Fllow this way, you can install more large grid tie power system to three phases, just seperate the whole power system to three equal power system units. Layout of Sunshine Grid Tie Power Inverter. Dump load resistor connection Terminal. This terminals will connect to the dump load resistor. AC socket, This socket will connect the inverter to the public grid via the AC cable. This terminals will connect to the wind turbine. Outline Drawing of SUN Series Grid Tie Power Inverter. Dimensions (W x H x D). Limiter with 2m cable? 7-10 / 2-7 work days. 12-15 / 2-7 work days. Italy, France, Germany, Russia, Brazil, Argentina. 25-30 / 2-7 work days. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. Contact us24 hours reply. This item is in the category “Home & Garden\Home Improvement\Electrical Supplies\Alternative Energy Supplies\Alternative Energy Chargers & Inverters”. The seller is “powmr-official” and is located in this country: CN.
- Current: 1000W DC22-65V+Limiter
- AC input: AC110V
- Power Factor: 0.99
- Output Wave Form: Pure Sine Wave
- MPPT Efficiency: 99%
- Over Current Protection: Yes
- Over Temperature Protection: Yes
- Reverse Polarity Protection: Yes
- Anti-Island Protection: Yes
- Stackable: Yes
- Color: Blue
- Brand: WIND
- Country/Region of Manufacture: China
- Wattage: 1000W
- Power Source: Wind
- Power Type: 3 Phase Wind Turbine/Generator
- Display: LCD
- Output Frequency: 46Hz~65Hz
- Standby Power Consumption: <0.5W
- Total Harmonic Distortion: <5%
- Peak Inverter Efficiency: 92%
- Model: SUN series
- Charging Mode: MPPT (Maximum Power Point Tracking)
- Features: All Daylight Conditions, Indicator Light, PC Display, Temperature Control, USB Port, Wi-Fi Port, Smart Module, LCD Display, LED Indicator, Flexible
- Connector Type: MC4
- Application: Home/Garden
