1200W Waterproof Grid Tie Inverter DC 24V to AC 110V MPPT Function MC4 Connector. ECO-Worthy 1200W 24V 110V grid tie waterproof inverter , with MC4 waterproof interface suitable for outdroor. One 1200W 24V-110V waterproof inverter. One pouch of screw for micro inverter installation. Please connect the inverter following the operation instruction show above. If have any question please contact with relative persons. Non-professionals do not disassemble. Only qualified personnel may repair this product. Please install inverter in the low humidity and well-ventilated place to avoid the inverter over-heating, and clear around the inflammable and explosive materials. When using this product, avoid children touching, playing, to avoid electric shock. Recommend Use PV Panels. 1200W / Vmp>34V / Voc<50V. DC MAX Input Current. AC MAX Output Power. DC MAX Open-Circuit Input-Voltage. DC Input Voltage Range. MAX Output Power Factor. DC Input Reverse Voltage Protection. AC Output Voltage Range. Output Short Circuit Protection. Power Line Carrier-Current Communication. DIN VDE 1026 UL1741. Power line carrier-current communicationthis is optional function, please confirm the spec outside the box first. By using electric power as a carrier of AC alternating current, can modulate high-frequency and carrier frequency (60KHz) in AC wire transmission and can achieve the communication/ newsletter between inverters or between inverter and computer. And it can transfer the power data. Also monitor all functions of inverter. Carrier frequency 60KHZ(Frequency customizable). Interface way TTL level serial interface. Serial rate 9600PS(Can customize according to customer's request). 6-grade power search ---In overcast weather, the PV Panel's output current is extremely tiny, then inverter will automatic pen 6-grade power search function, and keep output efficient and steady during the low power. Wide voltage input(22-50VDC) --- 1. DC voltage input:2250VDC; 2. Second level power variable voltage conversion. High-frequency two-way and one-way grid function ---1. High frequency direct modulation, AC half wave synthesis; 2. Two-way grid means: Load consume directly. And can reverse AC current transmission. Kinds of frequency output function ---1. It can apply to 50Hz and 60Hz frequency of AC; 2. Frequency range: 45Hz 64Hz. Directly connected to the solar panels (do not need to connect the battery). AC 0 angle with high precision auto-detection ---High-precision analysing the AC phase angle. The phase shift rate is less than 1%, thus achieve high-precision with phase modulation AC output together. AC phase shift: < 1%; 2. Over-zero protection: 0.2 VAC; 3. AC switching: 50Hz / 60Hz. Synchronous High -frequency Modulation. Modulation synthesis: half wave and full-bridge modulation synthesis (100Hz / 120Hz). Synthetic way: MOSFET full-bridge; 3. Pure Sine Wave Output ---Use SPWM directly to make pure sine wave output. Output waveform: Adopt complementary PWM to push-pull pure sine wave; 2. Generate means: enhancement-mode SPWM. Power Automatically Locked (APL) --- automatically powers locked in maximum power point, made output more stable. Constant Current, Constant Power ---constant current and output power, without any overload, over-current phenomenon. Exactly and timely automatic Island Effect Protection. High-Frequency High Conversion Rate --- Adapt high frequency converter, the output more efficient. Maximum Power Point Tracking (MPPT) --- high-precision (MPPT) operation power, automatic and immediate adjust the solar panels output power at the maximum output point, made the inverter discharge to power grid with the highest efficiency. Stack using ---Such as: 4 micro inverter of 260W stacking can achieve 1040W. The number of the stacking is unlimited. DC input ---Input voltage range: 22V to 50V, PV Panel: Recommend using the power more than 30W and the standard voltage of 36V PV panels. Suggestion making the PV in parallel. 220VAC: 180V - 262V, 50HZ; 110V AC: 80V - 160V , 60HZ. The item "1200W Waterproof Grid Tie Inverter DC 24V to AC 110V MPPT Function MC4 Connector" is in sale since Thursday, November 23, 2017. This item is in the category "Home & Garden\Home Improvement\Electrical & Solar\Alternative & Solar Energy\Chargers & Inverters". The seller is "renewtopsolar" and is located in Hollis, New York. This item can be shipped worldwide.

• Brand: ECO-WORTHY
• Model: 1.2KW 110V waterproof grid tie inverter
• MPN: GI1200-24120IP65-1
• Country/Region of Manufacture: China
• Input voltage: 22-50V
• Output voltage: 80-160V
• Package include: 1 pcs 1.2KW 110V grid tie inverter
• Ambient temperature range: -40 ~65
• AC MAX output power: 1200Watt
• DC MAX input current: 80A
• AC frequency range: 49.3-50.5 Hz / 59.3-60.5 Hz
• Certificate: CEC
• UPC: 607052788629
• Fit for: 2*18V or 36V solar panel
• Suitable for: 300W 36V solar panel
